Model: HSP-PH300F
Product origin: CHINA
Warranty: 1 Year
After-sales Service: Online Technical Support
Model: HSP-PH300F
Product origin: CHINA
Warranty: 1 Year
After-sales Service: Online Technical Support
Main Features
-High resolution LCD display, 7.0 inches.
-Multi-reading feature allows auto-read, timed-read and continuous-read.
-Automatic/Manual temperature compensation ensures accurate results.
-Auto-hold feature senses and locks the measurement endpoint.
-Data Storage 500 sets (GLP-compliant).
-USB and RS-232 communication.
-Reset feature automatically resumes all settings back to factory default options.
-IP54 waterproof.
-1-5 points calibration with Standard Recognition.
-Configurable pH buffer calibration with pre-set groups for NIST, DIN, GB, USA, and GOST standards.
-Automatic electrode diagnosis with pH slope and offset display.
Includes
-E-301-QC 3 in 1 pH composite electrode
-PH standard solution(4.01, 7.00, 10.01) ,50ml/vial
-REX-5 electrode stand
Specification
| Model | HSP-PH300F | |
| Parameters | pH/Temp.(mV) | |
| pH | Range | -2.00~20.00pH |
| Resolution | 0.1, 0.01 pH | |
| Accuracy | ±0.01 pH | |
| Calibration Points | Up to 5 | |
| Standard Customization | Yes | |
| Standard Recognition | NIST, GB, USA, DIN, GOST buffers | |
| mV | Range | -2000.0~2000.0 mV |
| Resolution | 0.1 mV | |
| Accuracy | ±0.3 mV or ±0.1% | |
| Temperature | Range | (-5~110)ºC, (23~230)ºF |
| Unit | ºC,ºF | |
| Resolution | 0.1 | |
| Accuracy | ±0.2ºC | |
| Measurement | Reading Mode | Auto Read (Fast, Medium, Slow), Timed, Continuous |
| Reading Prompts | Reading, Stable, Locked | |
| Temp. Compensation | ATC, MTC | |
| Data management | Data Storage | 500 results each |
| GLP Features | Yes | |
| Inputs | pH Electrode | BNC(Q9) |
| Temp. Probe | 4-pin aviation connector | |
| Outputs | USB | PC |
| RS 232 | printer | |
| Display options | Backlight | Yes |
| Auto Shutdown | 1~60 min, off | |
| IP Rating | IP54 | |
| Date and Time | Yes | |
| General | Power | EU Power Adapter (Input: AC 230V/50Hz; Output: DC 20V/1000mA). Configurable power adapter option available. |
| Dimensions | 242×195× 68 mm | |
| Net Weight | 900g (1.98 lb) | |
| Dimensions (Carton) | 370×320×220 mm | |
| Shipping Weight | 2.5 kg | |
