Medical Pharmacy Refrigerator

HSP-YC55EL 2℃–8℃ Benchtop Undercounter Pharmacy Refrigerator
HSP-YC55EL 2℃–8℃ Benchtop Undercounter Pharmacy Refrigerator
HSP-YC55EL 2℃–8℃ Benchtop Undercounter Pharmacy Refrigerator
HSP-YC55EL 2℃–8℃ Benchtop Undercounter Pharmacy Refrigerator
HSP-YC55EL 2℃–8℃ Benchtop Undercounter Pharmacy Refrigerator
HSP-YC55EL 2℃–8℃ Benchtop Undercounter Pharmacy Refrigerator
HSP-YC55EL 2℃–8℃ Benchtop Undercounter Pharmacy Refrigerator
HSP-YC55EL 2℃–8℃ Benchtop Undercounter Pharmacy Refrigerator

HSP-YC55EL 2℃–8℃ Benchtop Undercounter Pharmacy Refrigerator

Model: HSP-YC55EL

Product origin: CHINA

Warranty: 1 Year

After-sales Service: Online Technical Support


Share:

The HSP-YC55EL is a compact 2℃–8℃ benchtop or undercounter medical refrigerator designed for safe and reliable storage of vaccines, pharmaceuticals, biological samples and lab reagents in small spaces. Its precise temperature management and robust safety features provide consistent cold chain performance for pharmacies, clinics, laboratories, hospitals and pharmaceutical facilities.


Main Features

-Accurate 2℃–8℃ temperature control with high‑precision microprocessor and stable digital display (0.1℃ resolution) maintains reliable cold storage.

-Efficient air‑cooling system with automatic defrost and uniform temperature distribution.

-Audible and visual alarms for high/low temperature, power failure, sensor faults and door ajar to ensure product safety.

-Double layer foamed solid door with strong insulation for enhanced temperature retention.

-Built-in USB data logger for automated temperature recording and easy data export.

-Adjustable wire shelves customize storage layout to fit different products.

-Lockable front door to prevent unauthorized access.

-LED interior lighting for clear visibility and convenient operation.

-Eco‑friendly refrigerant and insulation for efficient energy‑saving operation.


Specification

2~8℃ Pharmacy Refrigerator
ModelHSP-YC55EL
Capacity(L)55
Internal size(W*D*H)mm444*440*404
External size(W*D*H)mm542*565*632
Package size(W*D*H)mm575*617*682
NW/GW(Kgs)35/59(wood packing)
Performance
Temperature range2~8℃
Ambient temperature16-32℃
Cooling performance5℃
Climate classN
ControllerMicroprocessor
DisplayDigital display
Refrigeration
Compressor1pc
Cooling methodForced air cooling
Defrost modeAutomatic
RefrigerantR600a
Insulation thickness(mm)L/R:48,B:50
Construction
External materialPCM
Inner materialAumlnum plate with spraying/Stainless steel
Shelves2 (coated steel wired shelf)
Door lock with keyYes
LightingLED
Access port1pc. Ø 25 mm
Casters2+2( leveling feet)
Data logging/Interval/Memory capacityUSB/Record every 10 minutes/12 months
Alarm
TemperatureHigh/Low temperature, High ambient temperature
ElectricalPower failure, Low battery
SystemSensor failure, Door ajar, Built-in datalogger
Standard accessories
SystemRS485, Remote alarm contact
