HSP-YC400L 2℃–8℃ Pharmacy & Medical Refrigerator

Model: HSP-YC400L

Product origin: CHINA

Warranty: 1 Year

After-sales Service: Online Technical Support


Share:

The HSP-YC400L Pharmacy & Medical Refrigerator is designed for reliable, stable storage of temperature-sensitive pharmaceuticals, vaccines, and laboratory materials. Featuring precise digital temperature control, uniform airflow, and intelligent alarm systems, it ensures that critical medical products are consistently maintained within a safe 2℃–8℃ range. Ideal for hospitals, pharmacies, clinics, and research laboratories.


Main Features

-Precise 2℃–8℃ temperature control with digital microprocessor and 0.1℃ display resolution

-Uniform cooling system with multi-duct airflow and frost-free operation

-Intelligent alarm system for high/low temperature, power failure, door ajar, and sensor faults

-Anti-condensation glass door with electric heating for clear visibility

-USB temperature data logging for traceable, long-term records

-400 L capacity with 6 adjustable PVC-coated steel shelves for organized storage

-Energy-efficient design using environmentally friendly R290 refrigerant

-LED interior lighting and convenient access for routine monitoring


Specification

2~8℃ Pharmacy Refrigerator
ModelHSP-YC400L
Cabinet typeUpright
Capacity(L)400
Internal size(W*D*H)mm604*520*1400
External size(W*D*H)mm700*645*2010
Package size(W*D*H)mm765*710*2074
NW/GW(Kgs)116/127
Performance
Temperature range2~8℃
Ambient temperature16~32℃
Preset temperature5℃
Climate classN
ControllerMicroprocessor
DisplayDigital display
Refrigeration
Compressor1pc
Cooling methodAir cooling
Defrost modeAutomatic
RefrigerantR290
Insulation thickness(mm)L/R:48, B:50
Construction
External materialPCM
Inner materialSprayed aumlnum plate /Stainless steel (optional)
Shelves6 (coated steel wired shelf)
Door lock with keyYes
LightingLED
Access port  1pc. Ø 25 mm
Casters4 (2 casters with brake)
Data logging/Interval/Memory capacityUSB/Record every 10 minutes/2 years
Door with heaterYes
Alarm
TemperatureHigh/Low temperature, High ambient temperature, Condenser overheating
ElectricalPower failure, Low battery
SystemSensor failure, Door ajar, Built-in USB datalogger Failure
Electrical
  Power Supply (V/HZ)220-240~50/60
Power (W)458
Power Consumption (KWh/24h)5.28
Rated Current (A)2.23
Accessories
StandardRS485, Remote alarm contact, Backup battery
