Model: HSP-HC30
Product origin: China
Warranty: 1 Year
After-sales Service: Online Technical Support
Model: HSP-HC30
Product origin: China
Warranty: 1 Year
After-sales Service: Online Technical Support
Main Features
-Slim shape, thickness is only 24mm,one-handed performance
-Easy operation with 4.0″touch LCD display, screen lock function
-16G mass storage, can store more than 100000 patient’s information and data
-Continuous real time when power off
-Patient’s information &data, tendency chart automatic storage when power off
-Auto brightness adjustment accordingto the environmental brightness changes
-Support 7-20 hours continuous work
Specification
| Size | 148(L)*76(W)*24(H) |
| Weight | 250g |
| Touch LCD display | 4″ 800*600 dpi |
| Internal memory | 16G SD card |
| Storage temperature | -20°C – 55 °C |
| Usage temperature | 0 – 40°C |
| Humidity | 15%-95% |
| Power | 5V DC,USB |
| Charger | 100-240V AC,50/60HZ |
| Lithium battery | 7V DC 3500mah |
| Continuous working time | 7 hour (CO2+SPO2) |
| Out put | USB, BLE, WLAN, SPO2 |
| Range | 0%-100% |
| Precision | ±2% ( 70%-100% Adult/Paed ),±3% ( 70%-100% Neonate ) |
| Resolution | ±1% |
| PR | |
| Range | 30-250BPM |
| Precision | ±1BPM |
| SPO2 | |
| Range | 0%-100% |
| Precision | ±2% (70%-100% Adult/Paed)±3% (70%-100% Neonate) |
| Resolution | ±1% |
| ETCO2 | |
| Range | 0-20% 0-150mmhg |
| Precision | ±2% 0-40mmhg±5470mmhg±8% 71-100mmhg±10% 101-150mmhg |
| Sampling rate | 50±10ml/min |
| AwRR | |
| Range | 3-160 rmp/min |
| Precision | ±1rpm |
| Gas compensation | O2, N2O and anesthetic |
| Pressure compensation | automatic 400-800 mmhg |
| Sampling tube | degermed, xerantic, intergrated, fast plug in & out related products |
