HSP-AED-S1 Automated External Defibrillator Machine

Model:HSP-AED-S1

Product origin: CHINA

Warranty: 1 Year

After-sales Service: Online Technical Support

Product Description

The HSP-AED-S1 Automated External Defibrillator is a compact and user-friendly life-saving device designed for the rapid treatment of sudden cardiac arrest (SCA). It utilizes advanced low-energy biphasic truncated exponential (BTE) waveform technology to deliver effective defibrillation while minimizing myocardial damage.

The device automatically analyzes the patient’s heart rhythm and provides clear voice instructions to guide the rescuer through the entire process. With its fast response time, durable design, and simple operation, the HSP-AED-S1 is suitable for both trained professionals and first responders in public and medical environments.

Designed for reliability and ease of use, the system supports rapid emergency response and helps improve survival rates in cardiac arrest situations.

Key Feature

Easy-to-use operation

• Simple 3-step operation with clear voice prompts

• Pre-connected electrode pads for quick deployment

• Suitable for both trained and non-professional users

Compact and portable design

• Lightweight design (approx. 1.6 kg)

• Easy to carry and install in various environments

Fast response performance

• Rapid rhythm analysis and pre-charging

• Ready to deliver shock within ≤7 seconds

Advanced defibrillation technology

• Biphasic truncated exponential waveform

• Automatically adjusts energy based on patient impedance

• Reduces heart damage while improving defibrillation efficiency

Safe and reliable

• Detects cardiac arrest even in patients with pacemakers

• Built-in safety logic prevents inappropriate shock delivery

Durable and environmentally resistant

• IP55 protection against dust and water

• Withstands 1.22 m drop from any direction

• Operates in a wide temperature range

Specification

Physical	Dimensions	98±10mm (L)×197±10mm (W)×67±10mm (H)
Physical	Weight (including battery and pads)	1.6±0.2kg
Environmental Conditions	Temperature and relativehumidity	Operating(with battery and pads installed) :0℃～50℃,5%～95% RH(non-condensing)Standby (with battery and pads installed) :5℃～35℃,5%～95% RH(non-condensing) Storage/shipping(with battery and pads ):-30℃～65℃ for up to 24 hours, 5%～95% RH(non-condensing)
	Atmosphere pressure	480hPa（Wave height 5920m）～1060hP
	Sealing	IP55
	Vibration	Operating: meets EN1789 random, road ambulance. Standby: meets EN1789 swept sine, road ambulance.
	Shock/Drop Resistance	Withstands 1.22 meter drop to any edge, corner, or surface.
Defibrillator	Waveform	Biphasic truncated exponential. Waveform parameters are automatically adjusted to patients’ impedances.
	Energy	Adult mode: 150 J nominal (±10%) delivered into a 50 ohm load.Child mode: 50 J nominal (±10%) delivered into a 50 ohm load.When the system detects impedance ≤ 20Ω or ≥ 200Ω, device will not deliver a shock.
	Charge time from shock-advised	≤ 7 seconds with a new battery
Pads	Pads type	Disposable, pre-gelled, self-adhesive, latex-free defibrillation pads
	Cable Length	120 cm ± 12 cm
	Active Gel Surface Area	F7952W/J: 100cm²±10cm² eachF7952PW/J: 40cm²±10cm² each
	Shelf Life	30 months from date of manufacture when stored and maintained according to directions provided in this manual.
Battery	Type	12VDC,4.2 Ah, LiMnO2 battery
	Capacity	New battery≥300 shocks (20℃±2℃).New battery≥100 shocks (0℃±2℃)
	Shelf Life	Shelf Life: 5 years from date of manufacture when stored and maintained according to directions provided in this manual.
