Model: HSP-201A
Product origin: CHINA
Warranty: 1 Year
After-sales Service: Online Technical Support
Model: HSP-201A
Product origin: CHINA
Warranty: 1 Year
After-sales Service: Online Technical Support
Main Features
-Integrated breathing circuit with APL valve, excellent tightness.
-Replacing drive bellow is NOT required when operating Adult/pediatric anesthesia .
-Applied with 1high-precision vaporizer. (with optional 2 Selectatec).
-7 inch screen with no dead space.
-Real-time detection for loops, Paw, BPM, VT and compliance.
-Comprehensive monitoring capabilities include ventilation parameters monitoring, preset parameters, alarm indication and breathing waveform monitoring.
-ACGO available to connect with T/ Bain circuit for open operation.
-Yoke system with back up cylinders (A type with11L size).
Specification
| Display screen: | 10.1 inch LCD |
| Gas source: | O2,N2O,Air (optional) |
| Pipeline Input Range: | 280~600kPa (40~85psi) |
| Vaporizer: | 1 Selectetac, maximum 2 mounts (Isoflurane/Enflurane/Sevoflurane/Halothane) |
| Flowmeter: | 4 tubes flowmeter Cascade. 0.1~15L/min O2, 0.1~15L/min N2O, 0.1~15L/min Air (optional) |
| Battery Power: | ≥3 hours |
| Ventilation modes: | VCV, SIMV, MANUAL, STAND-BY |
| Waveforms : | P-T, F-T, V-T |
| Monitoring: | VT,MV,BPM,Paw,FiO2 (optional) |
| Tidal Volume: | 50-1500ml |
| Respiration Rate Range: | 1-100 bpm (1-40 bpm under SIMV) |
| I/E: | 4:1-1:8 |
| Power: | AC 110V~240V, 50Hz/60Hz |
| Work Surface | Height(With casters) 149cm (58.6 inch) Width 90cm (35.4 inch)Depth 65.6cm(25.8 inch)Safe shelf loading 15 kg±0.5kg |
| Screen | 15.6 inch TFT LED screen, 1366*768 pixels (17”/19” Optional) |
| Gas control & supply | Electronic control gas mixer, O2, N2O, Air |
| Position for vaporizer | Dual positions (Selectatec bar) |
| ACGO | Standard |
| Electronic Flowmeter | O2, Air and N2O(numerical/bargraph) |
| By-pass | Standard |
| Ventilator Software | V-CMV, P-CMV, V-SIMV, P-SIMV, PRVC, PRVC-SIMV, Manual/Spont, CPAP, PSV, HLM |
| Spirometry loop | P-V,P-F,F-V, reference Loop |
| Spare Cylinder yoke | Optional (O2, N2O ) |
| Li-ion Battery | 1 battery, 4800mAhOptional (2 batteries, 9600mAh) |
| AGSS | Optional |
| Waveforms | Up to 4 waveforms |
| Auxiliary power outlets | 4 |
| Castors | Four castors(dual wheels 125mm) with 4 separate brakes |
| Drawers | 3 with lock |
| Reading lamp | LED lighting Included |
| Gas monitor module | Optional(CO2, AG) |
| Built-in Heater | Standard |
| O2 cell | Standard |
| Vaporizer | Optional (Draeger/Penlon/Northern) |
| Patient monitor | Optional |
| Suction Device | Optional |
